Solis
On Gird Inverter
Solis-3P(5-20)K-4G
Solis Three Phase Inverters
Models
Solis-3P5K-4GSolis-3P10K-4GSolis-3P17K-4GSolis-3P8K-4G
Solis-3P6K-4GSolis-3P12K-4GSolis-3P20K-4GSolis-3P15K-4G
- Max. efficiency 98.7%
- Wide voltage range and low startup voltage
- 2 MPPT design with precise MPPT algorithm
- THDi<1.5%, low harmonic distortion against grid
- Multiple protections levels
- Intergrated Export Power Manager (EPM)
Solis-(25-40)K-5G, Solis-(40-50)K-HV-5G
Solis 5G Three Phase Inverters
Models
400VSolis-25K-5GSolis-33K-5GSolis-40K-5GSolis-30K-5GSolis-36K-5G
480V
Solis-40K-HV-5G
Solis-50K-HV-5G
- 4 MPPT design with precise MPPT algorithm, effectively reducing string mismatch
- 8 strings intelligent monitoring, Smart I-V Curve Dignosis supported
- 50% DC overload,13A input for each PV string
- Over 98.8% Max. effciency
- Fuse free design to avoid fire hazard
- Type II surge arrester for both DC and AC
- Natural convection, Fan-less design,longer lifespan
- RS485/ Wifi/ GPRS interface integration, remote upgrade supported
Solis-(50-60)K, Solis-60K-HV
Solis Three Phase Inverters
Models
400VSolis-50KSolis-60K-4G
480V
Solis-60K-HV
- Max. efficiency 99%
- Wide voltage range and low startup voltage
- 4 MPPT input, each rated current is 28.5A, compatible with high power module
- THDi<3%, low harmonic distortion against grid
- Anti-resonance, supporting over 6MW parallelled in one transformer
- Perfect commercial site monitoring solution
- Intelligent redundant fan-cooling
Solis-80K-5G
Solis 5G Three Phase Inverters
Models
400VSolis-80K-5G
- Max. 13A per string, support 1.5 DC overloading capability
- 9 individual MPPT, lower dismatch loss
- Efficient logic algorithm, over 99% max. Efficiency
- String monitoring, shorter O&M time
- Remote & local intelligent IV scan function
- Leakage current repression technology
- Volt-watt work mode integrated
- DC input reverse alarm
- Optional anti-PID function integrated
- Reactive power compensation function
Solis-(80-110)K-5G-PRO
Solis Three Phase Inverters
Models
400VSolis-80K-5G-PROSolis-100K-5G-PROSolis-110K-5G-PRO
Efficient
- 6/8 MPPTs, max. efficiency 98.7%
- > 150% DC/AC ratio
- Compatible with bifacial modules
Safe
- IP66
- AFCI protection, proactively reduces fire risk
- Globally recognised branded componentry for
longer life
Smart
- Night SVG function
- Intelligent string monitoring, smart I-V curve scan
- Remote firmware upgrade with simple operation
Economic
- Power line communication (PLC) (optional)
- DC side supports “Y” connector
- Supports aluminium wire access to reduce cost
Solis-(100-110)K-5G
Solis 5G Three Phase Inverters
Models
400VSolis-100K-5GSolis-110K-5G
- 98.7% Max. effciency
- Wide voltage range and low startup voltage
- 10 MPPT design with precise MPPT algorithm
- THDi<3%, low harmonic distortion against grid
- Anti-resonance, supporting over 6MW parallelled in one transformer
- Perfect commercial site monitoring solution
- Intelligent redundant fan-cooling
- Strings intelligent monitoring, Smart I-V Curve Diagnosis supported
- Fuse free design to avoid fire hazard
- Type II surge arrester for both DC and AC, type I surge arrestor optional
- Leakage current repression technology
- Volt-watt work mode integrated
- DC input reverse alarm
- Optional anti-PID function integrated
- Integrated DC switches, AC switch optional
Solis-(215-255)K-EHV-5G
Solis Three Phase Inverters
Models
Solis-215K-EHV-5G-PLUS Solis-255K-EHV-5G Solis-255K-EHV-5G-PLUS
480V
Solis-60K-HV
Efficient
- 9/12/14 MPPTs, max. eYiciency 99%
- 200% DC/AC ratio
- High power tracking density 60MPPT/M
- Compatible with 500W+ bifacial modules
Safe
- IP66
- Built-in PID recovery for better module performance
- Fuse free design, safe and maintenance free
- Globally recognised branded component for longer life
Smart
- Night SVG function
- Intelligent string monitoring. Smart I-V
curve scan - Remote firmware upgrade with simple
operation
Economic
- Power line communication (PLC) (optional)
- DC side supports two sinks and one access
- Supports aluminium wire access to reduce cost
- Reserve DC energy storage access
